10 Technical Data
79
Technical Data GW8000-SDT-
AU30
GW9990-SDT-
AU30
Input
Max.Input Power (W) 12000 15000
Max.Input Voltage(V) 1,100 1,100
MPPT Operating Voltage Range (V) 140~950 140~950
MPPT Voltage Range at Nominal
Power (V)
*2
150~850 180~850
Start-up Voltage (V) 160
Nominal Input Voltage (V) 600 600
Max. Input Current per MPPT (A) 32/16/16
Max. Short Circuit Current per MPPT
(A)
45/23/23
Max.Backfeed Current to The Array(A) 0 0
Number of MPP trackers 3 3
Number of Strings per MPPT 2/1/1 2/1/1
Output
Nominal Output Power (W) 8,000 9,990
Nominal Output Apparent Power (VA) 8,000 9,990
Max. AC Active Power (W) 8,000 9,990
Max. AC Apparent Power (VA) 8,000 9,990
Nominal Output Voltage (V)
230/400, 3L/N/PE
or 3L/PE
230/400, 3L/N/PE
or 3L/PE
Output Voltage Range (V)
180- 260
(According to
local standard)
180- 260
(According to
local standard)
Nominal AC Grid Frequency (Hz) 50/60 50/60
AC Grid Frequency Range (Hz) 45~55 / 55~65 45~55 / 55~65
Max. Output Current (A) 11.6 14.5
Max. Output Fault Current (Peak and
Duration) (A)
37 @6.5us 37 @6.5us
Inrush Current (Peak and Duration)
(A)
28.1 @50us 28.1 @50us
Nominal Output Current (A) 11.6 @400Vac 14.5 @400Vac
