10 Technical Data
76
10 Technical Parameters
Technical Data GW5000-SDT-
AU30
GW6000-SDT-
AU30
Input
Max.Input Power (W) 7500 9000
Max.Input Voltage(V) 1100 1100
MPPT Operating Voltage Range (V) 140~950 140~950
MPPT Voltage Range at Nominal
Power (V)
*2
150~850 150~850
Start-up Voltage (V) 160
Nominal Input Voltage (V) 600 600
Max. Input Current per MPPT (A) 16/16/16
Max. Short Circuit Current per MPPT
(A)
23/23/23
Max.Backfeed Current to The Array(A) 0 0
Number of MPP trackers 3 3
Number of Strings per MPPT 1 1
Output
Nominal Output Power (W) 5,000 6,000
Nominal Output Apparent Power (VA) 5,000 6,000
Max. AC Active Power (W) 5,000 6,000
Max. AC Apparent Power (VA) 5,000 6,000
Nominal Output Voltage (V)
230/400, 3L/N/PE
or 3L/PE
230/400, 3L/N/PE
or 3L/PE
Output Voltage Range (V)
180- 260
(According to
local standard)
180- 260
(According to
local standard)
Nominal AC Grid Frequency (Hz) 50/60 50/60
AC Grid Frequency Range (Hz) 45~55 / 55~65 45~55 / 55~65
Max. Output Current (A) 7.3 8.7
Max. Output Fault Current (Peak and
Duration) (A)
26 @6.5us 26 @6.5us
Inrush Current (Peak and Duration)
(A)
19.3 @50us 19.3 @50us
