06 Electrical Connection
36
PV Strings Access Mode
NOTICE
For maximizing power generation, it is recommended to access PV strings in
the way as follows:
：Access one PV string ：Access two PV strings
PV Access Mode
When installing the inverter for the rst time, set corresponding MPPT connection mode
via LCD (optional) or Solar Go App (contact after-sales for setting details) based on actu-
al wiring mode. After setting completes, disconnect PV and AC power supply, and restart
the inverter. If there is no feedback of abnormal PV access mode from the inverter, the
setting is successful.
[1]：MPPT4 is only applicable to
GW40K-SDT-P30, GW30KLV-SDT-C30, GW50K-SDT-C30
.
PVstring
numbers
MPPT1 MPPT2 MPPT3 MPPT4
[1]
4
5
6
7
8
There are three PV access modes:
1. Independent mode (default): MPPT1, MPPT2, MPPT3, and MPPT4 are connected inde-
pendently.
2. Partially parallel mode: MPPT1 and MPPT2 connected in parallel; and MPPT3 and
MPPT4 connected independently.
3. Parallel mode: From MPPT1 to MPPT4 connected in parallel to the same PV module.
For specic selection of access modes, refer to Chapter 8 or Solar Go User Manual.
WARNING
• When there are multiple PV strings, it is recommended to maximize the connec-
tions of MPPTs.
• Use the delivered DC connectors. The manufacturer shall not be liable for the
damage if other incompatible connectors are used.
• The PV strings cannot be grounded. Ensure the minimum isolation resistance of
the PV string to the ground meets the minimum isolation resistance requirements
before connecting the PV string to the inverter.
• The DC input cable is prepared by the customer.
• DC input cable type: the outdoor photovoltaic cable that meets the maximum
input voltage of the inverter.
