10 Technical Data
119
Operating Temperature
Range (℃)
-30~+60
Derating temperature (℃) 45
Storage Temperature (℃) -40~+70
Relative Humidity 0~100%
Max. Operating Altitude (m) 4000
Cooling Method Natural Convection
User Interface LED, LCD (Optional), WLAN+APP
Communication RS485, WiFi+LAN+Bluetooth, 4G+Bluetooth(Optional)
Communication Protocols Modbus-RTU (SunSpec Compliant), Modbus-TCP
Weight (kg) 15.1
Dimension (W×H×D mm) 491*392*210
Noise Emission (dB) ＜30
Topology Non-isolated
Self-consumption at Night
(W)
<1
Ingress Protection Rating IP66
Anti-corrosion Class C4,C5(Optional）
DC Connector MC4 (4~6 mm² )
AC Connector OT terminal (Max. 10mm²)
Environmental Category 4K4H
Pollution Degree III
Overvoltage Category DC II / AC III
Protective Class I
The Decisive Voltage Class
(DVC)
PV : C
AC : C
Com : A
Active Anti-islanding Method AFDPF + AQDPF *1
Country of Manufacture China
*1: AFDPF: Active Frequency Drift with Positive Feedback, AQDPF: Active Q Drift with Positive
Feedback.
*2: For Brazil Max. Input Power (kW), GW8000-SDT-30 is 14.4, GW10K-SDT-30 is 18, GW12K-
SDT-30 is 21.6, GW15K-SDT-30 is 27, GW17K-SDT-30 is 30.6, GW20K-SDT-30 is 36.
*3: For Brazil and Chile, the Max. AC Active Power (kW) &Max. AC Apparent Power (kVA): GW4000-
SDT-30 is 4, GW5000-SDT-30 is 5, GW6000-SDT-30 is 6, GW8000-SDT-30 is 8, GW10K-SDT-30 is 10,
GW12K-SDT-30 is 12, GW15K-SDT-30 is 15.
*4: For Brazil and Chile, Max. Output Current (A) and Nominal Output Current (A): GW8000-
