10 Technical Data
115
Max. Output Fault Current
(Peak and Duration) (A)
230 (at 4.36μs) 230 (at 4.36μs)
Inrush Current (Peak and
Duration) (A)
26.4A (at 8.5ms) 26.4A (at 8.5ms)
Nominal Output Current (A)
*4
78.8
75.7 @380Vac
72.4 @400Vac
69.4 @415Vac
Power Factor ~1 (Adjustable from 0.8 leading to 0.8 lagging)
Max. Total Harmonic Distortion <3% <3%
Maximum output overcurrent
protection(A)
196.6 196.6
Eciency
Max. Eciency 98.00% 98.70%
European Eciency 97.10% 98.00%
Protection
PV String Current Monitoring Integrated Integrated
PV Insulation Resistance
Detection
Integrated Integrated
Residual Current Monitoring Integrated Integrated
PV Reverse Polarity Protection Integrated Integrated
Anti-islanding Protection Integrated Integrated
AC Overcurrent Protection Integrated Integrated
AC Short Circuit Protection Integrated Integrated
AC Overvoltage Protection Integrated Integrated
DC Switch Integrated Integrated
DC Surge Protection Type II Type II
AC Surge Protection Type II Type II
AFCI Optional Optional
Emergency Power O NA Optional
Rapid Shutdown Optional Optional
Remote Shutdown Optional Optional
PID Recovery Optional Optional
Power Supply at Night Optional Optional
Shadow scanning Integrated Integrated
General Data
