10 Technical Data
108
Technical Data GW40K-SDT-P30
Input
Max.Input Power (ｋW) ７ ２ ．０
Max.Input Voltage(V)
*1
1,100
MPPT Operating Voltage Range (V) 140-1000
MPPT Voltage Range at Nominal Power (V) 400-850
Start-up Voltage (V) 160
Nominal Input Voltage (V) 600
Max. Input Current per MPPT (A) 40
Max. Short Circuit Current per MPPT (A) 56
Max.Backfeed Current to The Array(A) 0
Number of MPP trackers 4
Number of Strings per MPPT 2
Output
Nominal Output Power (kW) 40.0
Nominal Output Apparent Power (kVA) 40.0
Max. AC Active Power (kW) 40.0
Max. AC Apparent Power (kVA) 40.0
Nominal Output Voltage (V) 220/380,230/400,240/415, 3L/N/PE or 3L/PE
Output Voltage Range (V) 180-280
Nominal AC Grid Frequency (Hz) 50/60
AC Grid Frequency Range (Hz) 45-55/55-65
Max. Output Current (A) 60.6
Max. Output Fault Current (Peak and Duration)
(A)
157(at 6.5μs)
Inrush Current (Peak and Duration) (A) 60(@500μs)
Nominal Output Current (A) 58.0
Power Factor ~1 (Adjustable from 0.8 leading to 0.8 lagging)
Max. Total Harmonic Distortion <3%
Maximum output overcurrent protection(A) 157
Eciency
Max. Eciency 98.6%
European Eciency 97.7%
Protection
PV String Current Monitoring Integrated
PV Insulation Resistance Detection Integrated
