10 Technical Data
103
Max. Output Fault Current (Peak and
Duration) (A)
157 (at 6.5μs) 157 (at 6.5μs)
Inrush Current (Peak and Duration) (A) 60 (at 500μs) 60 (at 500μs)
Nominal Output Current (A)
*4
60.4
56.9 @380Vac
54.4 @400Vac
52.1 @415Vac
Power Factor
~1 (Adjustable from 0.8
leading to 0.8 lagging)
~1 (Adjustable from 0.8
leading to 0.8 lagging)
Max. Total Harmonic Distortion <3% <3%
Maximum output overcurrent
protection(A)
157 157
Eciency
Max. Eciency 97.8% 98.6%
European Eciency 97.0% 97.8%
Protection
PV String Current Monitoring Integrated Integrated
PV Insulation Resistance Detection Integrated Integrated
Residual Current Monitoring Integrated Integrated
PV Reverse Polarity Protection Integrated Integrated
Anti-islanding Protection Integrated Integrated
AC Overcurrent Protection Integrated Integrated
AC Short Circuit Protection Integrated Integrated
AC Overvoltage Protection Integrated Integrated
DC Switch Integrated Integrated
DC Surge Protection Type II Type II
AC Surge Protection Type III (Type II Optional) Type III (Type II Optional)
AFCI Optional Optional
Emergency Power O
*３
ＮＡ ＮＡ
Rapid Shutdown Optional Optional
Remote Shutdown Integrated Integrated
PID Recovery Optional Optional
Power Supply at Night Optional Optional
