10 Technical Data
100
Max. Output Fault Current (Peak and
Duration) (A)
115,6.5μs 95,6.5μs 115,6.5μs
Inrush Current (Peak and Duration)
(A)
29.4 ,50μs
Nominal Output Current (A)
*4
43.5 36.3 43.5
Power Factor ~1 (Adjustable from 0.8 leading to 0.8 lagging)
Max. Total Harmonic Distortion <3%
Maximum output overcurrent
protection(A)
115 95 115
Eciency
Max. Eciency 97.5% 98.6% 98.6%
European Eciency 96.9% 98.2% 98.3%
Protection
PV String Current Monitoring Integrated
PV Insulation Resistance Detection Integrated
Residual Current Monitoring Integrated
PV Reverse Polarity Protection Integrated
Anti-islanding Protection Integrated
AC Overcurrent Protection Integrated
AC Short Circuit Protection Integrated
AC Overvoltage Protection Integrated
DC Switch Integrated
DC Surge Protection Type II Type III (Type II Optional)
AC Surge Protection Type III (Type II Optional )
AFCI Optional
Emergency Power O Optional
Rapid Shutdown Optional
Remote Shutdown Optional
PID Recovery Optional
Power Supply at Night Optional
General Data
Operating Temperature Range (℃) -30~+60
