06 Electrical Connection User Manual V1.2-2025-01-13
20
No. Cable Type Cable Specication
1 PE cable Outdoors Cable
Cross sectional area S
PE
≥ S/2. S is the cross
sectional area of the output phase wire.
2 DC cable
PV standard cable that
meets 1500V standard.
• Conductor cross-sectional area: 4~6mm
2
• Cable outer diameter: 5.5mm~8mm
3
AC cable (multi-
core)
Multi-core outdoor cable
• Cable outer diameter: 22mm~67mm
• Copper cable conductor cross sectional
Area: 70 ≤ S ≤ 240mm
2
• Aluminum alloy cable or copper-clad
aluminum cable conductor cross
sectional area: 95 ≤ S ≤ 240mm
2
4
AC Cable
(single-core)
Single-core outdoor
cable
• Cable outer diameter: 11mm~35mm
• Copper cable conductor cross sectional
Area: 70 ≤ S ≤ 240mm
2
• Aluminum alloy cable or copper-clad
aluminum cable conductor cross
sectional area: 95 ≤ S ≤ 240mm
2
• PE conductor cross sectional area S
PE
≥
S/2
5
RS485
communication
cable
Outdoor shielded
twisted pair. The cable
should meet local
requirements.
Cable length ≤ 1000m
6
Remote
shutdown cable
Outdoor shielded
twisted pair. The cable
should meet local
requirements.
N/A
Note:
The values in this table are valid only if the external protective earthing conductor is made of
the same metal as the phase conductors. Otherwise, the cross-sectional area of the external
protective earthing conductor is to be determined in a manner which produces a conductance
equivalent to that which results from the application of this table.
Only when the dimensions of the AC OT terminals after crimping and the rubber wall are as
below gures, the maximum cross sectional area of the single core cable can reach 400mm².
Contact After Sale Service for the rubber wall when the cross sectional area of the cable is
more than 240mm².
