03 Product IntroductionUser Manual V1.2-2025-01-13
9
No. Parts Description
1 DC Switch 1-3
Control PV input terminal 1-3, to connect or
disconnect the PV string.
2
PV Input Terminal 1-3
(Controlled by DC Switch 1-3)
Used to connect the PV strings.
3
PV Input Terminal 7-9
(Controlled by DC Switch 7-9)
Used to connect the PV strings.
4 DC Switch 7-9
Control PV input terminal 7-8, to connect or
disconnect the PV string.
5 DC Switch 4-6
Control PV input terminal 4-6, to connect or
disconnect the PV string.
6
PV Input Terminal 4-6
(Controlled by DC Switch 4-6)
Used to connect the PV strings.
7
PV Input Terminal
10-12(Controlled by DC Switch
10-12)
Used to connect the PV strings.
8 DC Switch 10-12
Control PV input terminal 10-12, to connect or
disconnect the PV string.
9 USB Port (Bluetooth)
Used to connect the Bluetooth communication
module.
10 Communication Port (RS485) Used to connect the RS485 communication cable.
11 Meter COM Port Used to connect the Meter cable.
12 AC Cable Outlet Hole To connect AC cables.
13
Communication Port (Remote
Shutdown / Emergency Power
O)
Used to connect the Remote Shutdown
communication cable.
14 DC Reset Switch
Reset the DC switch if it is tripped due to the inverter
fault. Press the RESET button using the reset tool and
turn the switch from OFF to ON.
15 DC Switch 1/ 2
Control PV input terminal 1-2, to connect or
disconnect the PV string.
16 PV Input Terminal 1-2 Used to connect the PV strings.
17 DC Switch 3/ 4
Control PV input terminal 3-4, to connect or
disconnect the PV string.
18 PV Input Terminal 3-4 Used to connect the PV strings.
19 PV Input Terminal 5-6 Used to connect the PV strings.
20 DC Switch 5/ 6
Control PV input terminal 5-6, to connect or
disconnect the PV string.
