3
Quick Installation Guide V1.1-2023-12-15
03
Technical Parameters
Model GMK110 GMK110D
Input
Grid Single-phase
Voltage
Nominal Voltage-Line
to N (Vac)
230
Voltage Range (Vac) 85-288
Nominal AC Grid
Frequency (Hz)
50/60
Current
Current Transformer
Ratio
120A: 40mA
Number of Current
Transformers
1 2
Communication RS485
Communication Distance (m) 1000
User interface 2 LED
Accuracy
Voltage/Current Class 1
Active Energy Class 1
Reactive Energy Class 2
Power Consumption (W) ≤5
Structural
Parameters
Dimensions (W×H×D mm) 19×85×67
Weight (g) 50
Mounting DIN rail
Environment
Parameters
Ingress Protection Rating IP20
Operating Temperature Range
(°C)
-30~+60
Storage Temperature Range (°C) -30~+70
Relative Humidity (non-
condensing)
0%~95%
Max. Operating Altitude (m) 3000
NOTE
The smart meter is mainly used for power control at the grid-connection point. The
measured energy yield and electricity consumption are for reference only and cannot be
used as a basis for calculating electricity fees. Electricity fee measurement is subject to the
meter provided by the grid company.
