P8
4.6 CARRYING
● To avoid damaging the cells, two workers are required to lift the four corners of the Galaxy
Plus (avoiding touching the position of the cells) at the same time when caring it.
● The downward bending distance of Galaxy Plus should not exceed 300mm when handled
manually. Please carefully position Galaxy into predestined location.
● Galaxy Plus should be carried upright as much as possible when handled manually. Do not
twist the product during transpoation and avoid front-facing products.
● Care is required during the handling of Galaxy Plus to avoid them bumping into the ground
or other sharp, hard objects.
4.7 INSTALLATION
Installation of Galaxy Plus by adhesive on colour steel tile roof.
Rule of applying structural adhesive:
● Galaxy Plus are bonded to the colour steel tile by structural adhesive, which needs to meet
the requirements for adhesive strength and pass reliability testing. Each product should be
equipped with no less than 6 strips of structural adhesive on the back (Figure 2) and the
spacing between each strip of structural adhesive should be as evenly distributed as possible.
The distance between two strips of structural adhesive should not be greater than 500mm.
● The distance that the product overhangs beyond the rib at each end should not exceed
50mm. (Figure 3)
Structural adhesive
≤ 500mm
FIGURE 2
