06 Electrical Connection
15
User Manual V1.2-2025-04-15
6 Electrical Connection
6.1 Safety Precaution
NOTICE
• Wear personal protective equipment like safety shoes, safety gloves, and insulating gloves
during electrical connections.
• All electrical connections should be performed by qualied professionals.
• Cable colors in this document are for reference only. The cable specications shall meet local
laws and regulations.
DANGER
• Before electrical connections, disconnect all upstream switches to ensure the device is not
energized. Do not work with power on. Otherwise, an electric shock may occur.
• Perform electrical connections in compliance with local laws and regulations. Including
operations, cables, and component specications.
• If the cable bears too much tension, the connection may be poor. Reserve a certain length
of the cable before connecting it to the equipment.
No. Cable Silkscreen Specication
1 PE cable
• Outdoor copper cable
• Conductor cross-sectional area: 2.5mm
2
- 4mm
2
(14AWG - 12AWG)
2
DC output cable
(12V/24V)
DC OUT / 12V
GND
• Outdoor copper cable
• Conductor cross-sectional area: 0.2mm
2
-
1.5mm
2
(24AWG - 16AWG)
3 DO signal cable DO 1-2
4
RS485
communication
cable
RS485 1-4
• Shielded twisted pair cable that meets local
standards
• Conductor cross-sectional area: 0.2mm
2
-
1.5mm
2
(24AWG - 16AWG)
5 DI signal cable DI 1-4
• Outdoor copper cable
• Conductor cross-sectional area: 0.2mm
2
-
1.5mm
2
(24AWG - 16AWG)
6 AI signal cable
AI_0-12V
AI_0/4-20mA
7 PT signal cable
PT100/
PT1000
8 Ethernet cable ETH 1-2
• CAT 5E or higher specications
• Shielded RJ45 connectors
