55
F400R V-mount Battery Power Supply
There is one V-mount battery slot on the left and right sides of theF400R controller, to
inserted one separately purchased 14.8V or 26V V-mount battery respectively.
①
When switching AC power supply to V-mount battery supply, please turn off the power
and unplug the power cord rst, and insert in the V-mount battery to turn on the power.
②
Only the left battery slot supports unilateral power supply. So if you only have one
battery, please insert it into the left battery slot to power the device on.
③
When the device is powered by two batteries, but one of which is in low power status,
the device still can not work normally even if the other one is fully charged, so it is
recommended to check in advance if both batteries have sufcient power.
Press the battery
locking pusher on the
left can pull out the
battery
Unilateral power
supply on the left
V-mount Battery
14.8V
26V
14.8V+14.8V
26V+14.8V
26V+26V
Linear
40%
60%
70%
90%
100%
S-curve
46.3%
54.5%
58.5%
71.6%
100%
Exponential
70%
82.2%
87.2%
96%
100%
Logarithmic
18.4%
31.5%
39.2%
63.4%
100%
Max.Brightness Values of F400R in Different Status
Power Switch
Press the power switch button on the controller after connecting to power source to turn
the unit on or off.
