* For warranty terms, conditions, and registration go to www.goalzero.com/warranty
To request a physical copy of the warranty call 1-888-794-6250.
General:
Rated Power 100 W
Cell Type Mono crystalline
Cell Efficiency 22.6%
Maximum System Voltage 1000 V DC
Operating Voltage 17.1 V
Operating Current 5.84 A
Open Circuit Voltage VOC 20.52 V
Short Circuit Current ISC 6.14 A
Series Fuse Rating 9 A
Temperature Coefficient (Power) -0.39%/°C
Temperature Coefficient (Voltage) -0.3 %/°C
Temperature Coefficient (Current) 0.06%/°C
Minimum bend radius 0.4 m in Y direction
Connector 4mm Solar Connector (compatible with MC4
connectors*)
Cable Length 2.95 ft (0.9 m) for each positive/negative cable
Cable AWG 12 AWG
Ingress Protection IP67
SKU 32425
Weight 4.63 lbs (2.1 kg)
Weight (In Box) 10.91 lbs (4.95 kg)
Dimensions 38.97 x 23.03 x 0.09 in (990 x 585 x 2.5 mm)
Note: With the junction box, the thickest part of the
panel is 0.74 in. (19 mm)
Dimensions (In Box) 24.13 x 1.69 x 40.39 in (613 x 43 x 1026 mm)
Operating Temperature Range -40° to 185° F (-40° to 85° C)
Certs
Limited Warranty 2 years*
Technical Specifications
Frequently Asked Questions
Can I plug the Flex 100i directly into a Goal Zero Yeti?
No. You need an MC4 to HPP adapter to connect the Flex 100i to a Yeti power
station.
How many solar panels can I connect together?
It varies depending on the device you’re pairing your panels with. For example,
the Goal Zero Yeti 4000 PRO will accept a maximum of 5 Flex 100i panels
in series, while the Yeti 1500X and all other ‘X’ line products can only
accommodate 2 panels in series.
Can I chain my Flex 100i with third-party solar panels?
No. The Flex 100i is not guaranteed to work with any other manufacturers’
products. Many solar panels are manufactured differently. Pairing your Flex
100i with third-party panels may result in product damage, fires, or other
serious issues.
How flexible is the Flex 100i?
The Flex 100i is most flexible when lengthwise. In this direction it can bend
at a 0.4 m radius. If the panel is forced to bend at a tighter radius than 0.4m,
it may result in lasting damage to the panel. If you are using the panel and it
seems to have maxed out on flexibility, do not force it to bend further.
EU DECLARATION OF CONFORMITY
Hereby, Goal Zero declares that the radio equipment type Flex 100i (32424) is
in compliance with Directive 2014/53/EU. The full text of the EU declaration of
conformity is available at the following internet address: https://www.goalzero.
com/pages/user-guides
