GLP German Light Products
X4 Atom PSU12 manual (v1.0) from software version: v1.21 5
3 Mounting
The X4 ATOM PSU 12 is fully operational whether it hangs or is mounted to
the wall. It can also be operated in a rack or standing on the floor or table.
Keep a safety distance of min. 0.5 m towards any easily inflammable
materials (decoration etc.).
Pay attention to the regulations of: BGV C1 (former VBG 70)
and DIN VDE 0711-217.
The installation shall be done by qualified staff only.
For the various mounting positions of the X4 ATOM PSU 12 (sideways or
hanging) different accessories kits are available. Through this a safe and firm
installation is assured. You'll find dedicated connectors on the top side of
the fixture which should be used.
3.1 Operating on the floor, on a table or in a Rack
The X4 ATOM PSU 12 can directly placed on the floor, a table or inside a
rack. An additional securing is usually not required. Please pay attention to
an even and gripping surface and keep at least 10cm space to each side
for ventilation.
Attention: Make sure not to not block any of the two fan in/outlets on either
side of the fixture.
3.2 Mounting in a hanging or sideways position
To operate the X4 ATOM PSU 12 in a hanging position an omega bracket
can be mounted directly to the top side of the PSU using the two Camlock
connectors.
It is fixed to the fixture with fasteners called Camlock quick-release
connectors. Insert the two fasteners and turn each 90° to lock them. Do the
opposite to release them again.
Alternatively a half-coupler (clamp or hook) can be mounted directly to the
top side of the PSU using the M10 x 11mm thread bolt.
Attention: Never use a longer bolt than 11mm as this may damage the
interior of the fixture.
