GLP
German Light Products GmbH (Instruction version 1.01) / from software version 1.07 7
2.1.2 Mounting in hanging position (Head down)
To operate the
V
V
O
O
L
L
K
K
S
S
L
L
I
I
C
C
H
H
T
T
S
S
P
P
O
O
T
T in an hanging position, please
attach one half-coupler centrically with a M10 thread bolt (max. length 11
mm). You can also use a dedicated mounting plate which is attached to
the fixture through two Camlock quick connectors
see section below.
2-Camlock
M10
length max.11 mm
2.1.3 Mounting in a sideway Position
To operate the
V
V
O
O
L
L
K
K
S
S
L
L
I
I
C
C
H
H
T
T
S
S
P
P
O
O
T
T in a sidewise position, please use
the dedicated mounting plate which is attached to the fixture two
Camlock quick connectors.
This technique is necessary to cope with the torque which accrues in this
mounting position. In addition it allows a concentrically position between
two truss belts. Never use the "Mounting in hanging position" technique
described above to secure the fixture in a sideway position, as the
fixtures base can become damaged, and a secure installation cannot be
assured.
