GLP
German Light Products GmbH (Instruction version 1.01) / from software version 1.07 21
7 Technical Specifications
Power supply
Power consumption
400 VA (Watt)
Power Input/Output
~100-240 V AC, 50-60 Hz (auto sensing input)
Power connectors
NEUTRIK
®
powerCON
Power-in: NAC3FCA / NAC3MPA (blue)
Power-out: NAC3FCB / NAC3MPB (grey)
Fuse protection
Micro-fuse 5x20 mm, T5A
Operational Parameters
Max. Ambient
Temperature
45°C / 113°F (integrated overheating switch)
Mounting Position
Any (see chapter mounting)
Lighting System - Additive Color mixing
LED Type
300 Watt RGB LED Light Engine
Lifetime
Average service life: 20,000h
Wavelength optimized for maximum presentable color space
Optical System
Fixed beam angle 13°
Variable CTO control from 2500k - 10.000k
Focus
Motorized Focus, 2m - infinity
Shutter / Dimmer, electrical
Strobe- Effect with variable speed between 1 - 10 flashes per second, Random-Strobe, Pulse-
Effects
Continuous Dimmer 0 - 100%
Prism
Rotating 3-facet prism, bi-directional and variable in speed
Gobos
Gobo wheel 1: 7 interchangeable rotating and indexed gobos plus open, variable speed and
bi-directional
Gobo wheel 2: 11 fixed gobos plus open
Gobo dimensions: Glass gobo thickness: 1.1 - 3.0mm
Aluminum gobo thickness: 0.5mm / Outside diameter: 23 mm / Image size: max. 19 mm.
For customized gobos like company logos and text the recommended image size is 16 mm.
DMX Control
Standard USITT DMX-512, 3&5 pin XLR; [+] = Pin 3 [-] = Pin 2 [Ground] = Pin 1 [4/5 n.c.]
The DMX- start address is [001] on DMX channel 1.
Pan/Tilt (8/16 Bit)
Pan- movement 660° in min. 2 seconds, with position feedback
Tilt- movement 300° in min. 1 seconds, with position feedback
Weights and Measures
Width of the base
320
Length of the base
288 mm (incl. handles)
Height (head vertical)
540 mm
Weight (net)
15 kg
