Je bekijkt pagina 16 van 26
GLP
German Light Products GmbH (Instruction version 1.01) / from software version 1.07 16
Extended-Mode 20 DMX channels
Channel Function Time and Value DMX HEX %
1) PAN-
coarse
0 .. 660° 0..255 00..FF 0..100
2) PAN-fine
High- Pos ... High- Pos + 2,6° (16 Bit) 0..255 00..FF 0..100
3) Tilt-
coarse
0 .. 300° 0..255 00..FF 0..100
4) Tilt-fine
High- Pos … High- Pos + 1,2° (16 Bit) 0..255 00..FF 0..100
5) Red-
coarse
Color mixing system - Red 0 - 100% 0..7 00..07 0..2,5
6) Red-fine
Color mixing system – Red low 0..255 00..FF 0..100
7) Green-
coarse
Color mixing system - Green 0 - 100% 0..255 00..FF 0..100
8) Green-
fine
Color mixing system – Green low
9) Blue
coarse
Color mixing system - Blue 0 - 100%
10) Blue-fine
Color mixing system – Blue low 0..255 00..FF 0..100
11) Shutter
Shutter closed 0..15 00..0F 0..5,5
Random Pulse effect
4)
slow - fast 16..47 10..2F 6..18,5
Up-dimming then Shutter closing
(random patterns)
4)
slow - fast 48..79 30..4F 19..31
Shutter open then down-dimming
(random patterns)
4)
slow - fast 80..111 50..6F 32..43
Up-dimming then down-dimming
(random patterns)
4)
slow - fast 112..143
70..8F 44..56
Strobe effect pause 5s .. 1s 144..199
A0..C7 57..77
Strobe effect, slow - fast 1 Hz .. 10 Hz 200..239
C8..EF 78..94
Shutter open 240..255
F0..FF 94.4..100
12) Dimmer-
coarse
Dimmer 0 - 100% 0..255 0..FF 0..100
13) Dimmer-
fine
Dimmer low
14) Gobo 1
Open position 0..15 0..0F 0..5.5
(indexed)
Gobo 1 16..31 10..1F 6..12
Gobo 2 32..47 20..2F 12.5..18
Gobo 3 48..63 30..3F 19..24.5
Gobo 4 64..79 40..4F 25..31
Gobo 5 80..95 50..5F 31.5..37
Gobo 6 96..111 60..6F 38..43.5
Gobo 7 112.129 70..81 44..50.5
Gobo rotation CCW slow
fast 130..192
82..C0 51..75
Gobo rotation CW fast
slow 193..254
C1..FE 75.5..99
Gobo rotation Stop 255 FF 100
15) Gobo 1
Gobo position 0 ... 540° 0..127 00..7F 0..49
Posi./Rot.
Gobo rotation STOP 128..129
80..81 50
Gobo rotation CW slow
fast 130..192
82..C0 51..75
Gobo Rotation CCW fast
slow 193..254
C1..FE 76..99
16) Gobo 2
Open position 0..7 00..07 0..2.5
(fixed)
Gobo 1 8..15 08..0F 3..5.5
Gobo 2 16..23 10..17 6..9
Gobo 3 24..31 17..1F 9.5..12
Gobo 4 32..39 20..27 12.5..15
Gobo 5 40..47 28..2F 15.5..18
Gobo 6 48..56 30..38 18.5..22
