GLP
German Light Products GmbH (Instruction version 1.01) / from software version 1.07 14
Channel Function Time and Value DMX HEX %
3 180° 20..21 14..15 8,0
3 270° 22..23 16..17 8,8
PAN 4 0° 24..25 18..19 9,6
4 90° 26..27 1A..1B 10,4
4 180° 28..29 1C..1D 11,2
4 270° 30..31 1E..1F 12
TILT size / phase see also PAN 32..63 20..3F 13..25
PAN / TILT size / phase see also PAN 64..95 40..5F 26..37
PAN / TILT (inverse) size / phase see also PAN 96..127 60..7F 38..50
Circle size / phase see also PAN 128..159
80..9F 51..62
Circle (inverse) size / phase see also PAN 160..191
A0..BF 63..75
Lying eight size / phase see also PAN 192..223
C0..DF 76..87
Random movement size see also PAN 224..255
E0..FF 88..100
20) Speed
Pan/Tilt relative movement 0..01 00..01 0..1
Pan/Tilt
Pan/Tilt slow – fast
Use this channel also for the SPEED of
the movements
02..255 02..FF 1.5..100
Compressed-Mode 17 DMX channels
Channel Function Time and Value DMX HEX %
1) PAN-
coarse
0 .. 660° 0..255 00..FF 0..100
2) PAN-fine
High- Pos ... High- Pos + 2,6° (16 Bit) 0..255 00..FF 0..100
3) Tilt-
coarse
0 .. 300° 0..255 00..FF 0..100
4) Tilt-fine
High- Pos … High- Pos + 1,2° (16 Bit) 0..255 00..FF 0..100
5) Color
Colors adjustable via RGB 0..7 00..07 0..2,5
(fixed)
Color 01 - Red
1)
8..15 08..0F 3..5,5
Color 02 - Amber
1)
16..23 10..17 6..8,5
Color 03 - Warm Yellow
1)
24..31 18..1F 9..12,5
Color 04 - Yellow
1)
32..39 20..27 13..15,5
Color 05 - Green
1)
40..47 28..2F 16..18,5
Color 06 - Turquoise
1)
48..55 30..37 19..21,5
Color 07 - Cyan
1)
56..63 38..3F 22..24,5
Color 08 - Blue
1)
64..71 40..47 25..27,5
Color 09 - Lavender
1)
72..79 48..4F 28..30,5
Color 10 - Mauve
1)
80..87 50..57 31..34,5
Color 11 - Magenta
1)
88..95 58..5F 35..37,5
Color 12 - Pink
1)
96..103 60..67 38..40,5
White - CTO 104..111
68..6F 41..43,5
White 112..119
70..77 44..46,5
White - CTB 120..127
78..7F 47..49,5
Rainbow Effect Stop
2)
128 80 50
Rainbow Effect
3)
slow - fast 129..223
81..DF 51..88
Rainbow Effect, random colors slow - fast 224.255 E0..FF 89..100
6) Red
Color mixing system - Red 0 - 100% 0..255 00..FF 0..100
7) Green
Color mixing system - Green 0 - 100% 0..255 00..FF 0..100
8) Blue
Color mixing system - Blue 0 - 100% 0..255 00..FF 0..100
9) Shutter
Shutter closed 0..15 00..0F 0..5,5
Random Pulse effect
4)
slow - fast 16..47 10..2F 6..18,5
Up-dimming then Shutter closing
(random patterns)
4)
slow - fast 48..79 30..4F 19..31
