www.glp.de GLP Mad Maxx
28 MAD MAXX Quick Start and Safety Manual
9. Technical specifications
Light source
19 x 90 W white LEDs
LED PWM frequency options: Low (550 Hz) / Optimal (dynamic algorithm) / High 1
(4 600 Hz) / High 2 (13 000 Hz). All values rounded up/down; for detailed
information please contact GLP Support)
LED lifetime: 20 000 hours to 50% output*
*Figure obtained under manufacturer’s test conditions
Optical system
19 x output lenses with full circular aperture, front diameter 750 mm / 29.5 in.
Fixture CCT: 6 500 K (+/-200K)
Fixture CRI (Ra): 70+ (default), 90 with high CRI filter on color wheel deployed
Beam angle (half-peak): 1.6°
Fixture output: Up to 3 580 lm per beam, total output 68 000 lm (calculated)
Maximum peak luminous intensity: 4.7 Mcd per beam
Output aperture diameter: 750 mm / 29.5 in.
Movement
Pan range: Normal = 540°, Extended = 650°
Tilt range: 200°
Control resolution: 16-bit
Position feedback: Yes
Fast pan/tilt movement
Control and programming
Control protocols: DMX via USITT DMX512-A, Art-Net and sACN protocols, GLP
iQ.Mesh / LumenRadio CRMX, RDM (ANSI/ESTA E1.20)
DMX control modes: 3 (Normal, Segment, MultiBeam)
NFC sensor
16-bit control: Pan and tilt, intensity, color wheel (in Color Wheel model)
Standalone operation: One captured scene (SkyFX in preparation)
Setting and addressing: Onboard control panel with invertible backlit graphic display,
DMX, RDM, GLP iQ.Mesh smartphone app
Display power: Self-charging buffer battery
Firmware update: DMX Link via DProg, GLP iQ.Mesh
Effects
1 mechanical color wheel per Beam (in MAD MAXX CW fixture), each with variable
CTO area and 18 fixed colors including High CRI enhancement and CTB.
Virtual shutter: Variable speed with effects, instant open and blackout
Dimming: 0 – 100% continuous with 16-bit resolution, Linear, Soft and S-Curve
dimming curve options
Virtual iris effect
