German Light Products GLP MAD MAXX
Rev. 20250625-1 15
3. Fixture overview
A – Lens array
B – Cooling vents
C – Eyelets for shackles when lifting
D – Fixture yoke
E – Fixture base
F – Tilt lock
G – Light sensor (sun protection system)
H – Connections panel
I – Control panel and backlit LCD display,
NFC sensor behind display
J – Pan lock
K – Handle for guiding the fixture only – do
NOT use to support the fixture’s
weight!
L – Neutrik EtherCON port A for Art-
Net/sACN control data (fail-safe)
M – DMX IN (5-pin XLR)
N– Primary fuse
O – Mains power input
(Neutrik powerCON TRUE1)
P – Pressure equalization valve
Q – DMX OUT/THRU (5-pin XLR)
R – Neutrik EtherCON port B for Art-
Net/sACN control data (fail-safe)
B
A
H
G
C
C
C
K
E
I
F
G
C
D
G
L
M
R
N
Q
P
O
J
