8 JDC Line 500 User Manual
JDC Line 1000
The JDC Line Series includes the JDC Line1000, which is twice the length and has twice
the performance of the JDC Line 500. The JDC Line1000 has the advantage that it only
requires one power connection, one data connection and one control panel to run
1000 mm of JDC Line fixture. Internally, the JDC Line 1000 has two separate strobe and
effect engines, which lets you operate it as if it was two separate 500 mm fixtures.
The DMX channel layout of the JDC Line1000 is based on the layout of 2 x JDC Line
500s. This means that you can simply patch two JDC Line 500s next to each other to
control one JDC Line 1000. The Control / Settings channel of the second patched
fixture is ignored – the JDC Line 1000 uses the Control / Settings channel of the first
patched fixture only.
Fixture setup
The JDC Line 500 has an onboard control panel with a graphic display (see ‘Control
menus and onboard display’ on page 16) that you can use to configure the fixture’s
settings. You can also access all the fixture’s important settings remotely via DMX on
the fixture’s Control / Settings channel (DMX channel 6 in all DMX modes).
Strobe effects
The JDC Line 500 features RGBW strobe effects that you can run on all the fixture’s LEDs
together over a background with RGBW control. It also offers RGB and White strobe
effects that you can run separately. Again, you can run White and RGB strobe effects
over a background with RGBW control.
All strobe effects feature a powerful effects engine with pre-programmed patterns.
You can snap between patterns and between steps in patterns, or you can crossfade
with variable fade times.
Individual cell control
Some of the DMX control modes provide individual control of the white or RGB
segments.
On the JDC Line 500, the line of powerful White LEDs can be split into 20 segments. The
line of powerful RGB LEDs can also be split into 20 segments with the additional
possibility of separating the top and bottom half of each segment to give individual
control of 40 RGB pixels.
The JDC Line1000 offers 2 x 20 White and RGB segments that can be controlled like 2 x
JDC Line 500s.
For normal pixel-mapping applications (MultiPix Mode) the upper and lower half of
each RGB Segment are controlled at the same time. Advanced pixel-mapping mode
(MultiPix Advanced Mode) allows individual control of the top and bottom part of the
pixel.
RGB Pattern selection offers both segment Patterns and split-segment patterns.
Quad segment control
The Quad segment control available in DMX Mode 7 gives control of the white and/or
RGB segments in five groups, each consisting of four segments.
