30 JDC Line 500 User Manual
DMX Mode 7: MultiPix Quadpix
38 DMX Channels
White segments overall control gives
overall output control of the
individually controllable White
segments at the end of this DMX mode
(see below). It offers the standard
strobe channels for intensity and strobe
effects.
RGB segments overall control gives
overall output control of the
individually controllable RGB segments
at the end of this DMX mode (see
below). It offers the standard strobe
channels for intensity and strobe
effects and a CTC Channel which lets
you adjust the color temperature of
the white output.
Strobe phase lets you shift the timing of
RGB segments strobe by 1 – 359°
relative to the strobe on the White
segments. A 180° shift will result in a
flipflop between flashes on the two
strobes.
Background color sets a background
color on the RGB segments. As
standard, the main color output always
has higher priority than the
background color. You can define
how background color and main color
are mixed using Background color on
the Control/Settings channel.
White quad segments divides the 20
White segments into 5 quad segments,
each containing 4 segments, and gives
intensity control. The overall output of
these quad segments is determined by
the White segments overall control
channels (see above).
RGB quad segments divides the 20 RGB
segments into 5 quad segments, each
containing 4 segments, and gives RGB
control. The overall output of these
Mode 7
MultiPix Quadpix
White strobe
1
Intensity coarse
2
Intensity fine
3
Duration
4
Flash rate (Shutter)
5
Intensity effects (Strobe mode)
6
Control / Settings
RGB strobe
7
Intensity coarse
8
Intensity fine
9
Duration
10
Flash rate (Shutter)
11
Intensity effects (Strobe mode)
12
CTC
13
Strobe phase
Background color
14
Intensity background
15
Red background
16
Green background
17
Blue background
18
White background
White quad segments
19
White quad segment 1
…
…
23
White quad segment 5
RGB quad segments
24
Red quad segment 1
25
Green quad segment 1
26
Blue quad segment 1
…
…
36
Red quad segment 5
37
Green segment 5
38
Blue segment 5
quad segments is determined by the
RGB segments overall control channels
(see above).
Control / Settings lets you configure the
fixture remotely via DMX.
