28 JDC Line 500 User Manual
DMX Mode 5: Multipix
98 DMX Channels
White segments overall control gives
overall output control of the
individually controllable White
segments at the end of this DMX mode
(see below). It offers the standard
strobe channels for intensity and strobe
effects.
RGB segments overall control gives
overall output control of the
individually controllable RGB segments
at the end of this DMX mode (see
below). It offers the standard strobe
channels for intensity and strobe
effects and a CTC Channel which lets
you adjust the color temperature of
the white output.
Strobe phase lets you shift the timing of
the RGB segments strobe by 1 – 359°
relative to the strobe on the White
segments. A 180° shift will result in a
flipflop between flashes on the two
strobes.
Background color sets a background
color on the RGB segments. As
standard, the main color output always
has higher priority than the
background color. You can define
how background color and main color
are mixed using Background color on
the Control/Settings channel.
White segments individual control
adjusts the output of the individual
White segments. The overall output of
these segments is determined by the
White segments overall control
channels (see above).
RGB segments individual control
adjusts the color of the individual RGB
segments. The output of these
segments is determined by the RGB
segments overall control channels (see
above).
Mode 5
MultiPix
White segments overall control
1
Intensity coarse
2
Intensity fine
3
Duration
4
Flash rate (Shutter)
5
Intensity effects (Strobe mode)
6
Control / Settings
RGB segments overall control
7
Intensity coarse
8
Intensity fine
9
Duration
10
Flash rate (Shutter)
11
Intensity effects (Strobe mode)
12
CTC
13
Strobe phase
Background color
14
Intensity background
15
Red background
16
Green background
17
Blue background
18
White background
White segments individual control
19
White segment 01
…
…
38
White segment 20
RGB segments individual control
39
Red segment 01
40
Green segment 01
41
Blue segment 01
…
…
96
Red segment 20
97
Green segment 20
98
Blue segment 20
The upper and lower halves of each RGB
segment are controlled together, giving
individual RGB control of 20 RGB pixels in
total.
Control / Settings lets you configure the
fixture remotely via DMX.
