26 JDC Line 500 User Manual
DMX Mode 3: W Strobe + RGB Pixel
84 DMX Channels
White strobe with FX runs on the White
segments only and has an effects
engine with 50 patterns. Crossfading
sets the duration of changes between
the steps in each pattern. Transition
sets the duration of changes from one
pattern to the next.
Pattern chain length lets you set up a
chain of fixtures for the pattern to run
across in a chase by defining the total
number of fixtures in the chain. Pattern
chain position lets you set which
position in the chain the fixture will
occupy: first, second or third etc. fixture
in the chain.
RGB segments overall control gives
overall output control of the
individually controllable RGB segments
at the end of this DMX mode (see
below). It offers the standard strobe
channels for intensity and strobe
effects and a CTC Channel which lets
you adjust the color temperature of
the white output.
Strobe phase lets you shift the timing of
the RGB segments strobe by 1 – 359°
relative to the strobe on the White
segments. A 180° shift will result in a
flipflop between flashes on the two
strobes.
Background color sets a background
color on the RGB segments. As
standard, the main color output always
has higher priority than the
background color. You can define
how background color and main color
are mixed using Background color on
the Control/Settings channel.
Mode 3
W Strobe + RGB Pixel
White strobe with FX
1
Intensity coarse
2
Intensity fine
3
Duration
4
Flash rate (Shutter)
5
Intensity effects (Strobe mode)
6
Control / Settings
7
Pattern select
8
Pattern step / speed
9
Pattern step crossfade
10
Pattern transition
11
Pattern chain length
12
Pattern chain position
RGB segments overall control
13
Intensity coarse
14
Intensity fine
15
Duration
16
Flash rate (Shutter)
17
Intensity effects (Strobe mode)
18
CTC
19
Strobe phase
Background color
20
Intensity background
21
Red background
22
Green background
23
Blue background
24
White background
RGB segments individual control
25
Red segment 01
26
Green segment 01
27
Blue segment 01
…
…
82
Red segment 20
83
Green segment 20
84
Blue segment 20
RGB segments individual control adjusts
the color of the individual RGB segments.
The output of these segments is
determined by the RGB segments overall
control channels (see above).
The upper and lower halves of each
segment are controlled together, giving
20 RGB pixels.
Control / Settings lets you configure the
fixture remotely via DMX.
