14 JDC Line 500 User Manual
Display orientation
Depending on which way up you install the fixture, you can change the orientation of
the control panel display:
● Auto: The readout in the display is automatically turned through 180° if the fixture is
installed upside-down.
● Normal: The readout in the display is the right way up when the fixture is placed with
the display closer to the right-hand end of the fixture, close to the Mains Power
OUT/THRU connector, as shown in Figure 1 on page 6.
● Inverted: The readout in the display is turned through 180°.
You can change the Display orientation setting on the Control / Settings DMX channel,
in the Fixture Settings menu in the fixture’s control panel, or via RDM.
Custom settings presets
The JDC Line 500 sets you set up three different fixture configurations and save them as
custom presets. A configuration includes all of the fixture’s personality settings
(dimming curve, pixel orientation etc.) but does not include DMX address, DMX mode
and control protocol type.
Calling up a preset let you quickly recall configurations that you have set up in
advance to match different uses or different environments.
You can save custom presets and load custom presets via DMX on the Control /
Settings DMX channel. You can also save custom presets in the Service → Advanced
→ Save Settings menu and load custom presets in the Fixture Settings menu in the
fixture’s control panel.
Fixture information
The Information menu in the control panel gives access to items of information from
the fixture’s sensors and memory. You can check temperature sensor readouts, see
total operating hours counters and power cycle count, and see DMX signal quality
data, for example.
Manual control
If the JDC Line 500 is connected to mains power you can control it without using a
DMX controller if you open the Manual Control menu in the control panel.
This menu also lets you reboot the fixture.
If the fixture is connected to a DMX controller, it is also possible to take a snapshot of all
the DMX values that the fixture is receiving using a Capture DMX Values command.
These values are then applied as manual control values and stored in memory. Each
time that you enter the Manual DMX menu, the fixture will use these values until you
adjust them or apply a Reset Manual Values command.
