German Light Products
®
Rev. 20240618-01 35
Strobe’s RGB segments overall control
channels (see above).
The RGB segments on each Strobe are
split into upper and lower halves with
individual control of each half. This
gives individual RGB control of 40 RGB
pixels on Strobe A and 40 RGB pixels on
Strobe B.
Control / Settings lets you configure the
fixture remotely via DMX. Settings that
you configure on the Control / Settings
channel apply to both Strobe A and
Strobe B.
Strobe B White strobe
159
Intensity coarse
160
Intensity fine
161
Duration
162
Flash rate (Shutter)
163
Intensity effects (Strobe mode)
164
No function
Strobe B RGB strobe
165
Intensity coarse
166
Intensity fine
167
Duration
168
Flash rate (Shutter)
169
Intensity effects (Strobe mode)
170
CTC
171
Strobe phase
Strobe B Background color
172
Intensity background
173
Red background
174
Green background
175
Blue background
176
White background
Strobe B White segments individual
control
177
White segment 01
…
…
196
White segment 20
Strobe B RGB segments individual control
(upper, lower separately)
197
Red segment 01
198
Green segment 01
199
Blue segment 01
…
…
314
Red segment 40
315
Green segment 40
316
Blue segment 40
