German Light Products
®
Rev. 20240618-01 33
RGB segments overall control channels
(see above) for each strobe.
The upper and lower halves of each
RGB segment are controlled together,
giving individual RGB control of 20 RGB
pixels for Strobe A and 20 RGB pixels for
Strobe B.
Control / Settings lets you configure the
fixture remotely via DMX. Settings that
you configure on the Control / Settings
channel apply to both Strobe A and
Strobe B.
Strobe B White segments overall control
99
Intensity coarse
100
Intensity fine
101
Duration
102
Flash rate (Shutter)
103
Intensity effects (Strobe mode)
104
Control / Settings
Strobe B RGB segments overall control
105
Intensity coarse
106
Intensity fine
107
Duration
108
Flash rate (Shutter)
109
Intensity effects (Strobe mode)
110
CTC
111
Strobe phase
Strobe B Background color
112
Intensity background
113
Red background
114
Green background
115
Blue background
116
White background
Strobe B White segments individual
control
117
White segment 01
…
…
136
White segment 20
Strobe B RGB segments individual control
137
Red segment 01
138
Green segment 01
139
Blue segment 01
…
…
194
Red segment 20
195
Green segment 20
196
Blue segment 20
