German Light Products®
JDC Line 1000 User Manual 21
Pixel Mirror
Off
Normal pixel order: 1 to 10
(Pixel 1 is at Power IN)
x-mirror
Reversed pixel order: 10 to 1
(Pixel 1 is at Power OUT)
y-mirror
Inverted pixel order
(Pixel 11 to 20 on top row)
x-y-mirror
Reversed and inverted pixel order
(Pixel 20 to 11 on top row)
Pixel Mirror: x-mirror (A only)
Reversed pixel order: First pixel =
bottom row left, last pixel is top row
left, viewed from front
(applies to Section A only)
Pixel Mirror: y-mirror (A only)
Inverted pixel order: First pixel = top
row right, last pixel = bottom row
left, viewed from front
(applies to Section A only)
Pixel Mirror: x-y-mirror (A only)
Reversed and inverted pixel order:
First pixel = bottom row right, last
pixel is top row left, viewed from
front
(applies to Section A only)
Pixel Mirror: x-mirror (B only)
Reversed pixel order: First pixel =
bottom row left, last pixel is top row
left, viewed from front
(applies to Section B only)
Pixel Mirror: y-mirror (B only)
Inverted pixel order: First pixel = top
row right, last pixel = bottom row
left, viewed from front
(applies to Section B only)
Pixel Mirror: x-y-mirror (B only)
Reversed and inverted pixel order:
First pixel = bottom row right, last
pixel is top row left, viewed from
front
(applies to Section B only)
Fixture Order
Normal
Section A is at Power IN end of
fixture, Section B is at Power OUT
Reversed
Section A is at Power OUT end of
fixture, Section B is at Power IN
Background Color
Crossfade
Crossfading from background
color to main color
Mix
Main color mixes with background
color
Override
Main color completely overrides
background color
No Signal
Blackout
If DMX signal absent, fixture blacks
out
Hold
If DMX signal absent, fixture holds
last DMX values received
Houselight
If DMX signal absent, fixture goes to
constant white light
Fan Mode
Regulated
Fan speed regulated
High
Fans run at constant high speed,
output reduced if necessary
Medium
Fans run at constant medium
speed, output reduced if
necessary
Low
Fans run at constant low speed,
output reduced if necessary
