DMX Mode 3: Segments
41 DMX channels
Segments DMX Mode is split into a
Main Module and a Sub Module.
The Main Module gives control of the
main functions, as in Basic DMX Mode.
Pan, tilt, dimming and the color mixing
channels have 16-bit control resolution.
A shutter channel gives direct change
between open and blackout plus a
range of intensity effects. Zoom is also
available with 8-bit resolution. The
Control/Settings channel lets you
adjust fixture settings via DMX. Two
insert accessory channels allow control
of an optional GLP accessory mounted
on the head of the fixture.
The color control channels in the Main
Module offer color mixing using either
(a) RGB, (b) RGBL or (c) x;y color
gamut coordinates, depending on
which of these three methods is active.
You can select the color mixing
method via DMX on the
Control/Settings channel, via RDM or
using the fixture’s control panel.
Additional color options channels
include a color wheel with a wide
range of color presets, a CTC channel,
magenta/green shift adjustment and a
tungsten simulation channel. The CQC
channel lets you select if the fixture
should give priority to color rendering
or output intensity in its white output.
This channel also offers an easy way of
desaturating colors.
The Mix Priority channel defines how
the output of the Main and Sub
Modules is merged or overlayed.
The Sub Module forms a second layer.
The Sub Module channels provide
intensity and shutter control, a
powerful static and dynamic pattern
effects engine with step crossfading
and pattern transition options, plus
Mod
Mode 3
Segments
Main module
1.1
Pan
1
2
Tilt
3
4
Intensity
5
6
Shutter
7
Zoom
8
Control / Settings
9
Accessory 1
10
Accessory 2
11
[1] RGB – Red
[2] RGBL – Red
[3] x;y – x
12
13
[1] RGB – Green
[2] RGBL – Green
[3] x;y – y
14
15
[1] RGB – Blue
[2] RGBL – Blue
[3] x;y – not used
16
17
[1] RGB – not used
[2] RGBL – Lime
[3] x;y – not used
18
19
Color wheel
20
CTC (Color temperature control)
21
CQC (Color quality control)
22
M/G shift
23
Tungsten simulation
24
Mix priority
25
Sub module
1.2
Intensity Layer 2
26
27
Shutter Layer 2
28
Pattern selection Layer 2
29
Pattern step / speed Layer 2
30
Pattern step crossfading Layer 2
31
Pattern transition Layer 2
32
1.3
Red, segment 01
33
Green, segment 01
34
Blue, segment 01
35
1.4
Red, segment 02-07
36
Green, segment 02-07
37
Blue, segment 02-07
38
1.5
Red, segment 08-19
39
Green, segment 08-19
40
Blue, segment 08-19
41
RGB color control of three pixel groups as
segments.
