German Light Products®
Rev. 20240207-01 27
See Figure 2. The top line of the default information screen consists of, from left to right:
● Main CPU firmware version
● DMX Mode
The center of the screen shows the following information:
● Signal source.
● Fixture’s current DMX address in large characters. If the fixture’s self-diagnosis
system detects an error, the fixture will flash the error code alternately with the DMX
address. This lets you see the DMX address and error code at a distance from the
fixture.
● If the fixture detects a valid, active network at one of the fixture’s etherCON ports,
the default screen will show a network icon to the left or right of the DMX address:
- Icon on left = data at Port A (on left of fixture when facing control panel)
- Icon on right = data at Port B (on right of fixture when facing control panel)
The fixture displays network speed below the network icon.
If the fixture does not detect a network at one of the ports, it displays NO LINK
instead of the network icon for that port.
● Below the current DMX address, the fixture displays in smaller characters the DMX
channels that the fixture is currently using.
In the example shown in Figure 2:
● The fixture is running CPU software version 1.1.3
● The fixture is set to DMX Mode 1
● The fixture is set to receive data via DMX
● The fixture’s DMX start address is 001
● The fixture is using DMX channels 1 to 24.
Note: See ‘Setting up the control protocol’ on page 30 for details of how to configure
the fixture’s network address.
Using the control panel
The four control panel buttons under the display have the following functions.
In the main screen:
QUICK MENU – Activates the Quick Menu
UP/DOWN – Press three times to open the live diagnostic tool
MENU – Activates the control panel if it is in sleep mode, then opens
the main menu
