DMX Mode 5: Multipix Compressed

RGB

63 DMX Channels

MultiPix Compressed RGB DMX Mode

gives control of the main functions, as

in Basic DMX Mode, plus RGB color

control of each individual pixel. Tilt

and dimming have 16-bit control

resolution. A shutter channel gives

direct change between open and

blackout plus a range of intensity

effects. Zoom is also available with 8-

bit resolution. The Control/Settings

channel lets you adjust fixture settings

via DMX.

The CTC Channel lets you temporarily

change from the fixed white point to

any other color temperature. The

CQC channel lets you select if the

fixture should give priority to color

rendering or output intensity in its

white output. This channel also offers

an easy way of desaturating colors.

RGB color mixing is carried out on the

individual pixel control channels.

Mode 5

Multipix Compressed RGB

Main module

1.1

Tilt

1

2

Intensity

3

4

Shutter

5

Zoom

6

Control / Settings

7

CTC (Color temperature control)

8

CQC (Color quality control)

9

Sub module (Layer 2)

1.2

Red, pixel 01

10

Green, pixel 01

11

Blue, pixel 01

12

1.3 … 1.18

RGB, pixels 02-17

13

…

60

1.19

Red, pixel 18

61

Green, pixel 18

62

Blue, pixel 18

63
