German Light Products® X5 IP Bar 1000

Rev. 20240207-01 41

DMX Mode 3: Segments

48 DMX channels

Segment DMX Mode is split into a Main

Module and a Sub Module.

The Main Module gives control of the

main functions, as in Basic DMX Mode.

Tilt, dimming and the color mixing

channels have 16-bit control

resolution. A shutter channel gives

direct change between open and

blackout plus a range of intensity

effects. Zoom is also available with 8-

bit resolution. The Control/Settings

channel lets you adjust fixture settings

via DMX.

The color control channels in the Main

Module offer color mixing using either

[1] RGB, [2] RGBL or [3] x;y color

gamut coordinates, depending on

which of these three methods is

active. You can select the color

mixing method via DMX on the

Control/Settings channel, via RDM or

using the fixture’s control panel.

Additional color options channels

include a color wheel with a wide

range of color presets, a CTC channel,

magenta/green shift adjustment and

a tungsten simulation channel. The

CQC channel lets you select if the

fixture should give priority to color

rendering or output intensity in its

white output. This channel also offers

an easy way of desaturating colors.

The Mix Priority channel defines how

the output of the Main and Sub

Module is merged or overlayed.

The Sub Module forms a second layer.

The Sub Module channels provide

intensity and shutter control, a

powerful static and dynamic pattern

effects engine with step crossfading

and pattern transition options, plus

RGB color control of six pixel groups as

segments.

Mod

Mode 3

Segment

Main module

1.1

Tilt

Intensity

Shutter

Zoom

Control / Settings

[1] RGB – Red

[2] RGBL – Red

[3] x;y – x

[1] RGB – Green

[2] RGBL – Green

[3] x;y – y

[1] RGB – Blue

[2] RGBL – Blue

[3] x;y – not used

[1] RGB – not used

[2] RGBL – Lime

[3] x;y – not used

Color wheel

CTC (Color temperature control)

CQC (Color quality control)

M/G shift

Tungsten simulation

Mix priority

Sub module (Layer 2)

1.2

Intensity

Shutter

Pattern selection

Pattern step / speed

Pattern step crossfading

Pattern transition

Fixture quantity

Fixture number

1.3

Red, segment 1 (pixels 01-03)

Green, segment 1 (pixels 01-03)

Blue, segment 1 (pixels 01-03)

1.4

Red, segment 2 (pixels 04-06)

Green, segment 2 (pixels 04-06)

Blue, segment 2 (pixels 04-06)

1.5

Red, segment 3 (pixels 07-09)

Green, segment 3 (pixels 07-09)

Blue, segment 3 (pixels 07-09)

1.6

Red, segment 4 (pixels 10-12)

Green, segment 4 (pixels 10-12)

Blue, segment 4 (pixels 10-12)

1.7

Red, segment 5 (pixels 13-15)

Green, segment 5 (pixels 13-15)

Blue, segment 5 (pixels 13-15)

1.8

Red, segment 6 (pixels 16-18)

Green, segment 6 (pixels 16-18)

Blue, segment 6 (pixels 16-18)
