10. DMX control modes overview

The following DMX control modes are available in the impression X5 IP Bar 1000.

DMX channels from 1 to 7 have the same functionality in all the DMX control modes.

DMX Mode 1: Basic

20 DMX Channels

Basic DMX Mode gives control of

the fixture’s main functions. Tilt,

dimming and the color mixing

channels are available with 16-bit

control resolution. A shutter channel

gives direct change between open

and blackout plus a range of

intensity effects. Zoom is also

available with 8-bit resolution. The

Control/Settings channel lets you

adjust fixture settings via DMX.

The color control channels offer

color mixing using either [1] RGB, [2]

RGBL or [3] x;y color gamut

coordinates, depending on which

of these three methods is active.

You can select the color mixing

method via DMX on the

Control/Settings channel, via RDM

or using the fixture’s control panel.

Additional color options channels

include a color wheel with a wide

range of color presets, a CTC

channel, magenta/green shift

adjustment and a tungsten

simulation channel. The CQC

channel lets you select if the fixture

should give priority to color

rendering or output intensity in its

white output. This channel also offers

an easy way of desaturating colors.

Mode 1

Basic

Main module

1.1

Tilt

1

2

Intensity

3

4

Shutter

5

Zoom

6

Control / Settings

7

[1] RGB – Red

[2] RGBL – Red

[3] x;y – x

8

9

[1] RGB – Green

[2] RGBL – Green

[3] x;y – y

10

11

[1] RGB – Blue

[2] RGBL – Blue

[3] x;y – not used

12

13

[1] RGB – not used

[2] RGBL – Lime

[3] x;y – not used

14

15

Color wheel

16

CTC (Color temperature control)

17

CQC (Color quality control)

18

M/G shift

19

Tungsten simulation

20
