www.glp.de X5 IP Bar 1000

16 impression X5 IP Bar 1000 User Manual

4. Fixture Settings

The settings described in this chapter let you customize the impression X5 IP Bar 1000.

Settings can be available in the control panel, via DMX and/or via RDM.

Color Mix modes

The Color Mix Mode setting offers three different options for color mixing:

RGB Mode

RGB Mode mixes color of the main and sub module(s) using Red, Green and Blue

channels. The Lime LED is mixed automatically using the fixture’s internal GLP iQ.Gamut

algorithm.

RGB Mode offers a clean default white light at open which is considered to be the

white point (RGB at 100%).

When the Color Mix Mode is set to RGB, the different DMX Modes have the following

functionality:

● Mode 1 – Basic

- Main Layer: RGB control of all pixels as one group with Lime mixed

automatically. Lime Channel has no function.

● Mode 2 – Normal

- Main Layer: RGB control of all pixels as one group with Lime mixed

automatically. Lime Channel has no function.

- Sub Layer: RGB control of all pixels as one group with Lime mixed automatically.

● Mode 3 – Segment

- Main Layer: RGB control of all pixels as one group with Lime mixed

automatically. Lime Channel has no function.

- Sub Layer: RGB control of each segment with Lime mixed automatically.

● Mode 4 – Multipix

- Main Layer: RGB control of all pixels as one group with Lime mixed

automatically. Lime Channel is dead.

- Sub Layer: RGB control of each pixel with Lime mixed automatically.

● Mode 5 – Multipix Compressed RGB

- RGB control of each pixel with Lime mixed automatically.

● Mode 6 – Multipix Compressed RGBL

- RGBL control of each pixel.

RGBL Mode

RGBL Mode mixes color of the main module using Red, Green, Blue and Lime

channels. The colors of the Sub module(s) are mixed with RGB only - always without

Lime. The color gamut is still calibrated to the impression X5 range, but the white point

(open) is not adjusted to the black body line and will show a white that is mixed using

100% RGBL.
