www.glp.de X5 IP Bar 1000

10 impression X5 IP Bar 1000 User Manual

In nearly all DMX modes, the Main module gives color mixing control of all eighteen

pixels together as one segment.

● Mode 1 (Basic) provides a Main module with color mixing control of all pixels

together as one segment.

● Mode 2 (Normal) adds a Sub module as a second layer with pattern effects and

color mixing of all pixels as one segment.

● Mode 3 (Segment) adds Sub modules as a second layer with pattern effects and

color mixing of three segments: the inner, middle and outer rings.

● Mode 4 (Multipix Advanced) adds Sub modules as a second layer with pattern

effects and RGB color mixing of each individual pixel.

● Mode 5 (Multipix Compressed RGB) is a pixel mapping mode which offers the main

overall control options plus RGB color mixing of each individual pixel.

● Mode 6 (Multipix Compressed RGBL) is a pixel mapping mode which offers the

main overall control options plus RGBL color mixing of each individual pixel.

Color mixing

The fixture’s Main module features 16-bit color mixing with RGB, RGBL or x;y (CIE 1931)

Color Mix control options. See ‘Color Mix modes’ on page 16.

Note: The Color Mix mode of the Sub module(s) is always RGB. For more details, see

‘Color Mix modes’ on page 16.

iQ.Gamut

iQ.Gamut is a new LED calibration technology from GLP that defines the color gamut

for the color mix channels. You can select one of a range of calibrated iQ.Gamuts for

the fixture to work within. This feature can be useful if you want to reproduce correct

colors or avoid TV camera clipping. See ‘iQ.Gamut’ on page 18.

Mix Priority

The Mix Priority channel defines how the color mixing output of the Main module (Layer

1) and the color mixing output of the Sub module(s) (Layer 2) are merged together – or

which value has higher priority. This lets you switch between the layers or create

special effects using both layers.

The Mix Priority channel gives the following options:

● Main + Sub (HTP) – The fixture takes whichever color value of the Main module or

Sub module is highest and uses that value to determine the output color (Highest

Takes Priority).

● Main Only – The Sub module color value is ignored. The fixture uses the color value

of the Main module.

● Sub Only – The Main module color value is ignored. The fixture uses the color value

of the Sub module.
