www.glp.de DMX MODE 2 X5 Compact
50 Rev. 20230928-01
DMX Mode 2: Normal (default)
33 DMX Channels
Channel
Command
DMX
range
Percent
%
Default
DMX
Fade
Main Module Basic Control
1
Pan coarse
Pan left → right
0
65535
0
100
32768
Fade
2
Pan fine
3
Tilt coarse
Tilt back → front
0
65535
0
100
32768
Fade
4
Tilt fine
5
Intensity coarse
Intensity 0 → 100%
0
65535
0
100
0
Fade
6
Intensity fine
7
Shutter
Closed
0
4
0
1.6
0
Snap
Single flash if value changed within
the range 005 → 009
5
9
2.0
3.5
Fade
Pulse slow → fast
10
39
3.9
15.3
Fade
Pulse opening slow → fast
40
69
15.7
27.1
Fade
Pulse closing slow → fast
70
99
27.5
38.8
Fade
Double flash slow → fast
100
129
39.2
50.6
Fade
Strobe random pixel slow → fast
130
159
51.0
62.4
Fade
Strobe random all slow → fast
160
199
62.7
78.0
Fade
Strobe sync all pixels slow → fast
200
250
78.4
98.0
Fade
Open
251
255
98.4
100
Snap
8
Zoom
Zoom narrow → wide
0
255
0
100
0
Snap
9
Control/Settings
See ’Control / Settings channel’ on page 78
10
RGB / RGBL / x;y
color control
(see ‘Key to
conversion of x
and y coordinates’
on page 80)
[1] RGB - Red coarse
[2] RGBL - Red coarse
[3] x;y - x coarse
0
65535
0
100
65535
Fade
11
[1] RGB - Red fine
[2] RGBL - Red fine
[3] x;y - x fine
12
[1] RGB - Green coarse
[2] RGBL - Green coarse
[3] x;y – y coarse
0
65535
0
100
65535
Fade
13
[1] RGB - Green fine
[2] RGBL - Green fine
[3] x;y - y fine
14
[1] RGB – Blue coarse
[2] RGBL - Blue coarse
[3] x;y – not used
0
65535
0
100
65535
Fade
15
[1] RGB - Blue fine
[2] RGBL - Blue fine
[3] x;y - not used
16
[1] RGB - not used
[2] RGBL - Lime coarse
[3] x;y - not used
0
65535
0
100
65535
Fade
17
[1] RGB - not used
[2] RGBL - Lime fine
[3] x;y - not used
