German Light Products® X5 Compact
impression X5 Compact User Manual 41
DMX Mode 2: Normal (default)
33 DMX channels
Normal DMX Mode is split into a Main
Module and a Sub Module.
The Main Module gives control of the
main functions, as in Basic DMX
Mode. Pan, tilt, dimming and the
color mixing channels have 16-bit
control resolution. A shutter channel
gives direct change between open
and blackout plus a range of intensity
effects. Zoom is also available with 8-
bit resolution. The Control/Settings
channel lets you adjust fixture settings
via DMX.
The color control channels in the Main
Module offer color mixing using either
[1] RGB, [2] RGBL or [3] x;y color
gamut coordinates, depending on
which of these three methods is
active. You can select the color
mixing method via DMX on the
Control/Settings channel, via RDM or
using the fixture’s control panel.
Additional color options channels
include a color wheel with a wide
range of color presets, a CTC
channel, magenta/green shift
adjustment and a tungsten simulation
channel. The CQC channel lets you
select if the fixture should give priority
to color rendering or output intensity
in its white output. This channel also
offers an easy way of desaturating
colors.
The Mix Priority channel defines how
the output of the Main and Sub
Modules is merged or overlayed.
The Sub Module forms a second layer.
The Sub Module channels provide
intensity and shutter control, a
powerful static and dynamic pattern
effects engine with step crossfading
and pattern transition options, plus
RGB color control of all 7 pixels as one
group.
Mode 2
Mode 2
Normal
Main module
1.1
Pan
1
2
Tilt
3
4
Intensity
5
6
Shutter
7
Zoom
8
Control / Settings
9
[1] RGB – Red
[2] RGBL – Red
[3] x;y – x
10
11
[1] RGB – Green
[2] RGBL – Green
[3] x;y – y
12
13
[1] RGB – Blue
[2] RGBL – Blue
[3] x;y – not used
14
15
[1] RGB – not used
[2] RGBL – Lime
[3] x;y – not used
16
17
Color wheel
18
CTC (Color temperature control)
19
CQC (Color quality control)
20
M/G shift
21
Tungsten simulation
22
Mix priority
23
Sub module
1.2
Intensity Layer 2
24
25
Shutter Layer 2
26
Pattern selection Layer 2
27
Pattern step / speed Layer 2
28
Pattern step crossfading Layer 2
29
Pattern transition Layer 2
30
Red, pixels 1-7
31
Green, pixels 1-7
32
Blue, pixels 1-7
33
