See Figure 2. The top line of the default information screen consists of, from left to right:
● Main CPU firmware version
● DMX Mode
The center of the screen shows the following information:
● Signal source.
● Fixture’s current DMX address in large characters. If the fixture’s self-diagnosis
system detects an error, the fixture will flash the error message alternately with the
DMX address. This lets you see the DMX address or error message at a distance from
the fixture.
● If the fixture detects a valid, active network at one of the fixture’s etherCON ports,
the default screen will show a network icon to the left or right of the DMX address:
- Icon on left = data at Port A (on left of fixture when facing control panel)
- Icon on right = data at Port B (on right of fixture when facing control panel)
The fixture displays network speed below the network icon.
If the fixture does not detect a network at one of the ports, it displays NO LINK
instead of the network icon for that port.
● Below the current DMX address, the fixture displays in smaller characters the DMX
channels that the fixture is currently using.
In the example shown in Figure 2:
● The fixture is running CPU software version 1.1.3
● The fixture is set to DMX Mode 1
● The fixture is set to receive data via DMX
● The fixture’s DMX start address is 001
● The fixture is using DMX channels 1 to 22.
Note: See ‘Setting up the control protocol’ on page 31 for details of how to configure
the fixture’s network address.
