German Light Products® X5 Compact
impression X5 Compact User Manual 11
● Main - Sub subtractive – The Sub module color value is subtracted from the Main
module color value.
● Sub - Main subtractive – The Main module color value is subtracted from the Sub
module color value.
● TrueColor Main over Sub Snap – Sub module color stays in the background. Main
module color has higher priority and will not mix with Sub module color. As soon the
Main module color value is greater than zero, Sub module color blacks out and the
fixture uses the Main module color.
● TrueColor Sub over Main Snap – Main module color stays in the background. Sub
module color has higher priority and will not mix with the Main module color. As
soon as Sub module color value is greater than zero, Main module color blacks out
and the fixture uses Sub module color.
● TrueColor Main over Sub Crossfade – Sub module color stays in the background.
Main module color has higher priority. If you fade in a Main module color, Sub
module color will crossfade to the Main module color.
● TrueColor Sub over Main Crossfade – Main module color stays in the background.
Sub module color has higher priority. If you fade in a Main module color, Sub
module color will crossfade to the Main module color.
● Main to Sub Crossfade – Manually crossfading from Main module color only → Main
and Sub module color (HTP) → Sub module color only.
White point
The white point is the default white that is obtained when the shutter is opened. The
impression X5 offers a choice of fixed white points in RGB Color Mix Mode, allowing
convenient use in different environments. For details of setting the white point, see
‘White point’ on page 16.
Color temperature control (CTC)
In addition to the choice of default fixed white point, the fixture offers Color
Temperature Correction (CTC) in all three color mixing control modes (RGB, RGBL and
x;y). The CTC Channel allows a temporary change of white point and offers a smooth
shift between whites from 10 000 K to 2 500 K following the black body line.
Depending on the selected Color Mix Mode (RGB, RGBL or x;y), if you select a color
temperature on the CTC channel, the fixture will no longer use the specific open color
and will instead use the selected color temperature.
If you select a color temperature on the CTC channel, it is still possible to manipulate
the color temperature using the RGB and RGBL channels.
Note: To obtain the desired color temperature on the CTC channel, all ColorMix
channels need to be set to 100%. If they are not at 100%, the system will mix color
relative to the selected white point of the CTC channel.
The CTC channel affects all the fixture’s modules. Setting the CTC channel to a specific
color temperature will affect the open white of the Main module and Sub modules.
