www.glp.de X5 Bar 1000
8 impression X5 Bar 1000 User Manual
3. Features
The impression X5 Bar 1000 is a powerful LED-based linear format lighting fixture from
GLP. It features a head that tilts through 195° with GLP’s patented fast movement
system.
The fixture contains 18 x 40 Watt RGBL LED sources. Each source features smooth, full
range color mixing with a homogenized Fresnel lens. The fixture also has motorized fast-
action zoom.
The fixture offers a powerful multi-layer color and zoom effects engine.
Fixtures feature an alignment system that lets you build unbroken lines of pixels, and
power and data can be daisy-chained for ease of installation. The impression X5 Bar
1000 can be placed upright on a level surface or suspended from a suitable structure
as described in the fixture’s Quick Start and Safety Manual.
A filter slide-in system with mounting channels on the front of the head allows optical
accessories from GLP (such as an asymmetric beamshaper filter) to be installed in
seconds without the use of tools.
Control options
The impression X5 Bar 1000 is compatible with DMX 512 and RDM control protocols.
Other control options via Ethernet are currently in preparation for inclusion in a future
firmware release.
The fixture also features GLP iQ.Mesh and GLP’s FPO (Flexible Protocol Option) Port. The
GLP iQ.Mesh Module allows easy configuration, control, service and maintenance via
the GLP iQ.Service App. The FPO port allows you to use control options such as
LumenRadio CRMX if a CRMX module accessory is installed. The CRMX and other FPO
modules can be supplied on request (GLP Service can give details).
Powering on
See Figure 2. Slide the tilt lock button towards the
center of the fixture to release the tilt lock before
applying power to the fixture.
When power is applied to the fixture and no valid
DMX signal is present, the head moves
automatically to its home position (tilt center).
Tilt
The impression X5 Bar 1000 has motorized tilt
movement with coarse and fine control channels.
Direction of tilt movement
With the fixture standing on the ground, increasing
the tilt DMX value moves the head towards the
front from its home position. Tilt direction can be reversed using the Fixture Settings →
Tilt Invert setting (see ‘Tilt invert’ on page 22) or via DMX on the Special/Control
channel. This can be useful when setting up symmetrical movement in multiple fixtures.
Figure 2. Tilt lock button
