www.glp.de X5 Bar 1000
12 impression X5 Bar 1000 User Manual
The CTC channel affects all the fixture’s modules. Setting the CTC channel to a specific
color temperature will affect the open white of the Main module and Sub modules.
Color Quality Control (CQC)
The CQC channel lets you modify the spectral mix of the white output in order to
achieve a balance between better color rendering or higher output intensity. The
following options are available:
● High Quality (HQ) deploys multiple LEDs to create a richer light spectrum that gives
improved color rendering but also slightly lower output. Color is mixed with priority
given to the best white color rendering quality. Saturated colors will have maximum
saturation at DMX 000 and will smoothly become unsaturated until they reach 0%
saturation (= white) at DMX value 127.
● High Output (HO) gives higher output intensity but reduced color rendering
performance. Color is mixed with priority given to the highest output in white.
Saturated colors will have maximum saturation at DMX 255 and will smoothly
become unsaturated until they reach 0% saturation (= white) at DMX value 128.
While using white light, the CQC channel lets you change between white with priority
on high-quality color rendering and white with priority on highest output. Additionally,
the CQC channel lets you smoothly desaturate colors. If you have set a saturated
color in the color mix, the CQC channel lets you smoothly desaturate the color from
saturated to fully unsaturated (i.e. white).
Note: The CQC channel affects all the fixture’s modules. Setting the CQC channel to a
specific value will affect the colors of the Main module and Sub modules.
Note: The HO and HQ CQC options only affect the color mix if the fixture is in RGB or x;y
Color Mix mode. In all other Color Mix modes this setting has no effect.
Magenta/Green Shift (M/G Shift)
The Magenta/Green Shift channel lets you move the color coordinate of a white point,
a mixed color or a selected CTC color along a vertical line on the color temperature
curve in all three Color Mix modes. The corresponding white point is either shifted
towards Green or Magenta.
If M/G Shift is enabled, it immediately affects all mixed colors as well as the color
temperature that is selected on the CTC channel. It has no effect on the colors of the
virtual color wheel.
Note: The M/G Shift channel affects the entire fixture. Setting the M/G Shift channel to
a specific value will affect the output of the Main module and Sub modules.
Color wheel
The impression X5 Bar 1000 features a virtual color wheel channel that gives quick
access to a wide range of LEE-referenced colors in all three Color Mix modes. Color
wheel color presets are always mixed with the best available spectrum. Color filter
color coordinates are based on a Source C (daylight) light source.
