GLP German Light Products GmbH
impression X4 BAR 20 manual (v1.8) from software version: v0.60 7
3.1.1 Operating on the Floor (Upright)
The IMPRESSION X4 Bar 20 is fitted with 4x solid rubber feet which allows a stable
standing of the fixture. An additional securing is usually not required. Please pay
attention to an even and gripping surface.
3.1.2 Mounting in hanging or sideways position
To operate the IMPRESSION X4 Bar 20 in a hanging position please use the two
(2) dedicated brackets supplied with your fixture. They are fixed to the base of the
fixture with fasteners called Camlock quick-release connectors. Insert the four
fasteners of each and turn each 90° to lock them. Do the opposite to release them
again.
3.2 Securing the Fixture
Regardless of the mounting method of the IMPRESSION X4 Bar 20 you'll have to
use a stipulated safety wire.
Attach the safety wire through the two attachment points shown below and connect
it to the primary support structure.
The safety attachment points can be deployed by simply swinging them out from
the base.
Pay attention to a safe and proper fastening. The safety cable must comply with
BGI 810-3 (EN 60598-2-17 Section 17.6.6) and be capable of bearing a static
suspended load that is ten times the weight of the fixture and all installed
accessories.
4 x Camlock for bracket #1
4 x Camlock for bracket #2
