GLP German Light Products GmbH
impression X4 BAR 20 manual (v1.8) from software version: v0.60 33
8 Technical Specifications:
Power supply
Power consumption
450 VA (Watt)
Power Input
Auto sensing 100-240 V AC, 50-60 Hz
Fuse protection
Micro-fuse 5x20 mm, T5A
Operational Parameters
Max. Ambient
Temperature
5° - 45°C (integrated overheating switch)
40°-113°F
Mounting Position
Any (see relevant chapter in the manual)
Lighting System - Additive Color mixing
LED Type
20 x Osram Ostar RGBW multi-chip
Lifetime
50,000 h
Wavelength optimized for maximum presentable color space
Optical System
Full RGBW / High efficient Collimator cluster
Exchangeable diffuser filters available (optional).
Shutter / Dimmer (8/16 Bit)
Strobe- Effect with variable speed between 1-10 flashes per second, Random- & Pulse-Effects
Continuous Dimmer 0 - 100%
Zoom
7 to 50 degree continuous high speed zoom
Optical Patterns
Several pre-defined beam patterns with direct access and manipulation.
Free control of every pixel, color and intensity
DMX Control
Standard USITT DMX-512, 5 pin XLR: [+]=Pin 3 / [-]=Pin 2 / [Ground]=Pin 1 / Pin 4&5 N.C.
The DMX- Addressing starts at the DMX channel [001].
Tilt (8/16 Bit)
Tilt- movement
210° in min. 1.5 seconds (Position Feedback)
Weights and Measures
Length
1000 mm / 39.4´´
Width
100 mm / 3.9´´
Height
240 mm / 9.4´´
Weight (net)
14.5 kg / 32 lbs
Weight with 2 brackets
16 kg / 35 lbs
