GLP German Light Products GmbH
impression X4 BAR 10 manual (v1.8) from software version: v0.60 24
28
Set 5 Blue
Color mixing system - Blue
0 - 100%
0..255
29
Set 5 White
Color mixing system - White
0 - 100%
0..255
30
Set 6 Red
Color mixing system - Red
0 - 100%
0..255
31
Set 6 Green
Color mixing system - Green
0 - 100%
0..255
32
Set 6 Blue
Color mixing system - Blue
0 - 100%
0..255
33
Set 6 White
Color mixing system - White
0 - 100%
0..255
34
Set 7 Red
Color mixing system - Red
0 - 100%
0..255
35
Set 7 Green
Color mixing system - Green
0 - 100%
0..255
36
Set 7 Blue
Color mixing system - Blue
0 - 100%
0..255
37
Set 7 White
Color mixing system - White
0 - 100%
0..255
38
Set 8 Red
Color mixing system - Red
0 - 100%
0..255
39
Set 8 Green
Color mixing system - Green
0 - 100%
0..255
40
Set 8 Blue
Color mixing system - Blue
0 - 100%
0..255
41
Set 8 White
Color mixing system - White
0 - 100%
0..255
42
Set 9 Red
Color mixing system - Red
0 - 100%
0..255
43
Set 9 Green
Color mixing system - Green
0 - 100%
0..255
44
Set 9 Blue
Color mixing system - Blue
0 - 100%
0..255
45
Set 9 White
Color mixing system - White
0 - 100%
0..255
46
Set 10 Red
Color mixing system - Red
0 - 100%
0..255
47
Set 10 Green
Color mixing system - Green
0 - 100%
0..255
48
Set 10 Blue
Color mixing system - Blue
0 - 100%
0..255
49
Set 10 White
Color mixing system - White
0 - 100%
0..255
The Pixel are numbered left to right 1 – 10 as shown below.
Tilt DMX Value = 0 / “Display” to the front / “Power & DMX In” to the left.
1)
The predefined colors can be used as start-colors for the Rainbow effect. Please select first a desired
start-color before you activate the rainbow effect. All IMPRESSION X4 Bar 10 will then start from that
color and will execute the rainbow effect synchronously. Different IMPRESSION X4 Bar 10 can have
different start-colors but will still execute the rainbow effect synchronously. If you choose a color different
from the ones marked with
1)
in the tables above the rainbow start-color will be red.
2)
Rainbow-effect Stop will pause this function. After resuming the rainbow-effect will be continued from
the current color.
Display
Power /
DMX In
Power /
DMX Out
