GLP German Light Products GmbH
(Instruction version 1.02) / from software version 1.02
4
1 Description of Device
1. Moving Head
2. Arm with various cooling vents
3. Tilt-lock to secure and lock the
tilt movement
4. Backlight LCD graphical menu
(data entry)
5. Base with various connectors
and Camlock mounting
system
6. DMX- Output (5 Pin)
7. DMX- Output (3 Pin)
8. Micro-fuse 6.3x32mm, T8A
9. Power Switch
10. 2x Safety wire points
11. Neutrik Powercon (Mains power
input)
12. Blank panel (primed for Ethernet)
13. DMX- Input (3 Pin)
14. DMX- Input (5 Pin)
Note: Only connect one cable to the
DMX Input / Output at the same time!
Base Side 1
10
6 7 8 9
10
Base Side 2
11 12 13
14
1
2
3
4
5
