German Light Products®
Rev. 20241209-01 7
3. Features
The GLP impression S500 Series builds on the GLP impression S350 series fixtures by
increasing the LED power to 500W giving 30% to 65% more output. In addition, the
optics, software and all connections and controls have been updated to the latest
technology. Compact construction, the identical S350 size factor and GLP’s baseless
design allow for an easy fixture integration.
The impression S500 Wash HC combines a proven high light quality (CRI and TLCI over
90), natural colour rendering and homogeneous illumination properties with the
intelligent function package and low-noise operation familiar from the S350.
The white LED engine with 26,000 lm at native 6,000 K produces a very balanced light
spectrum for excellent colour rendering (CRI and TLCI over 90). Its great light quality
guarantees natural and realistic skin colors and a total lumen output of 14,800 lm.
The 185mm fresnel lens offers very even illumination in the range of 6,9° Beam to 40°
field angle. The feature package includes a CMY color mixing system, an innovative CTC
color control system, a color wheel with 6 full colors and 4 color correction filters, a
motorized iris, a precise 4-blade framing system with blade tilt and framing rotation and
motorized 540°/565° pan and 256° tilt movement.
The IP20 compact housing only weighs 26,6 kg (58.6 lbs.) and allows low-noise
operation, making the fixtures perfect for noise sensitive professional applications such
as TV studios, theaters or musicals.
Control options
The impression S500 Wash is compatible with DMX 512, RDM, Art-Net, sACN and can be
fitted with a Lumenradio CRMX module.
When receiving Art-Net, sACN or CRMX the fixture can output the received data to the
DMX XLR port for use by other fixtures (Ethernet Config → Node option).
When no control data is being received you can set the fixture to Blackout, Hold the last
data or go to a stored stand alone scene (Fixture Settings → No Signal option).
The fixture also features GLP iQ.Mesh and may be fitted with an optional LumenRadio
CRMX module. The GLP iQ.Mesh Module allows easy configuration, control, service and
maintenance via the GLP iQ.Service App. Other FPO modules can be supplied on
request – GLP Service can give details.
User setting presets
You can store the current fixture option settings in one of 3 presets, this allows you to
recall the fixture options into a known state (Fixture Settings → Load Settings and
Service → Advanced → Save Settings).
Pan and Tilt
The impression S500 Wash has motorized pan and tilt movement with coarse and fine
(16 bit) control channels.
Direction of movement
With the fixture standing on the ground:
