22 GLP impression S350 Wash User Manual Rev. C
To configure the fixture for DMX control over a DMX cable link, open the menus in the
fixture’s control panel and make the following adjustments:
In the first menu (root menu), set the fixture’s DMX address to a suitable address.
In the ArtNet/sACN menu, set Capture Mode to DMX.
These settings will not be affected if you apply a Special Default command in the
fixture’s control panel or a Load setting defaults command on the Control/Settings
DMX channel.
Art-Net
The fixture’s Ethernet port is suitable for connection to an Art-Net network. Use CAT 6 or
higher Ethernet cable only for this network.
To configure the fixture to receive control data via Art-Net, open the menus in the
fixture’s control panel and make the following adjustments:
In the first menu (root menu), set the fixture’s DMX address to a suitable address.
In the ArtNet/sACN menu, set Capture Mode to Art-Net.
Configure all fixtures with their own unique IP addresses. To do this, you can either:
• set fixtures to generate their own IP addresses by choosing the ranges 2.x.x.x or
10.x.x.x (Art-Net specification),
• set fixtures to acquire IP addresses automatically by DHCP, or
• assign IP addresses manually by entering individual IP addresses and Subnet mask.
Select an Art-Net port/universe from 00000 (Network 0 / Subnet 0 / Universe 0) to
32767 (Network 7 / Subnet 15 / Universe 255). Note that the first Art-Net universe is
considered to be universe number 00000, not 00001.
These settings will not be affected if you apply a Special Default command in the
fixture’s control panel or a Load setting defaults command on the Control/Settings
DMX channel.
Note that it is possible to transmit DMX data as broadcast or unicast packages via Art-
Net. If a large number of universes (more than 30) is broadcast, data loss can occur. If
you suspect that this is happening, configure your console to unicast Art-Net DMX
packages to fixtures, or switch to sACN.
sACN
The fixture’s Ethernet port is suitable for connection to an sACN network. Use CAT 6 or
higher Ethernet cable only for this network.
To configure the fixture to receive control data via sACN, open the menus in the
fixture’s control panel and make the following settings:
In the first menu (root menu), set the fixture’s DMX address to a suitable address.
In the ArtNet/sACN menu, set Capture Mode to sACN.
Configure all fixtures with their own unique IP addresses. To do this, you can either:
• set fixtures to generate their own IP addresses by choosing the ranges 2.x.x.x or
10.x.x.x (Art-Net specification),
