18 GLP impression S350 Wash User Manual Rev. C
Figure 5 Mounting points in base
5. Preparation for use
Warning! Read ‘Safety’ starting on page 4 for important safety information
that you must understand before you install or operate the fixture.
Included Items
The impression S350 Wash is supplied with a power cable with a powerCON TRUE1
connector and a tripod with Camlock fasteners for use as a floor stand.
Orientation and location
The fixture may be rigged in any orientation following the instructions in this chapter or
placed on a level surface in locations where it is safe to stand the fixture.
Keep the head at least 0.2 m (8 in.) away from combustible materials (including
curtains and stage scenery) when the fixture is installed.
Make sure that there is no risk of collision when the head pans and tilts. Allow a
minimum center-to-center distance of 600 mm (23.6 in.) when installing impression S350
fixtures side by side.
Mounting fasteners in base
See Figure 5. The base of the fixture has two threaded holes A that accept M10 bolts or
screws, and four mounting points B that accept standard camlock quarter-turn
fasteners. The camlock center-to-center distance is 90 mm (3.54 in.).
A
B
B
B
B
A
